Hygienic, precise, and time-saving—perfect for industry and food

Increase the efficiency of your packaging line with our fully automatic bag inserter—the ideal bag-in-box solution for cartons, trays, or KLTs.

Our technology ensures that bags are inserted into your target packaging hygienically, quickly and with absolute process reliability – perfect for demanding production environments.

The machine forms flat bags, opens them precisely with a vacuum system, and places them cleanly and accurately in cartons or containers. Alternatively, you can also process pre-made bags.

The result: consistently high quality, less labor, and maximum operational reliability for your line.

👁

The advantages of the bag inserter

Fully automated bag handling: forming, opening, and insertion in a continuous process – ideal for bag-in-box solutions and inner liners.
Maximum process reliability: vacuum-assisted bag opening and positioning for consistent results.
Hygienic design: Designed for sensitive products such as food, pharmaceuticals, or technical bulk goods.
Flexible packaging options: Compatible with open cartons, trays, KLTs, and various bag materials.
Modular & integrative: Can be used individually or seamlessly integrated into complete packaging lines with carton erectors, filling systems, and sealing units.
Reduced personnel requirements: Fewer manual interventions thanks to automated processes.
Combination model carton erector + bag inserter Bag in Box: Space-saving and ergonomic
User-friendly operation: Touchscreen HMI, short setup times, low maintenance.

👁

Areas of application

Our bag and inliner inserters are used across a wide range of industries:

Food industry (e.g., granulates, powders, liquids)
Baked goods & frozen foods
Pharmaceutical and medical technology
Cosmetics & chemicals
Technical products and electronics

Bag-in-box packaging with a system

By combining cardboard and bags, bag-in-box technology not only protects the product, but also offers advantages in terms of transport, storage, and logistics. Our machine lays the foundation for efficient, sustainable, and hygienic packaging processes—for solid, liquid, and dusty products alike.

Model variants:

DEAPTF50

Modell:	DEAPTF50
Versiegelungsgeschwindigkeit	360-480 Pcs/H
Verpackungsgröße	L2000B1600H2250mm
Stromversorgung	380 V, 50 Hz, 6 kW
Luftdruck	600 NL/min, 0,6–0,8 MPa
Höhe des Ausgabetisches	600 mm
Maschinenabmessungen	L 2000 × B 1600 × H 2250 mm

DEAPT50

Modell:	DEAPT50
Fördergeschwindigkeit	360-480 Pcs/H
Beutelgröße	L300-500W300-400H300-400mm
Stromversorgung	380 V, 50 Hz, 6 kW
Luftdruck	600 NL/min, 0,6–0,8 MPa, 600 mm
Höhe des Ausgabetisches	600 mm
Maschinenabmessungen	L 2120 × B 1800 × H 1950 mm

DEAPT50H

Modell:	DEAPT50H
Förderbandgeschwindigkeit	1200-1500 PCS/H
Beutelgröße	L300-500 × B300-400 × H300-400 mm
Stromversorgung	380 V, 50 Hz, 8 kW
Luftdruck	600 NL/min, 0,6–0,8 MPa
Höhe des Ausgabetisches	650 mm
Maschinenabmessungen	L 2200 × B 1900 × H 2200 mm

DEAPT50Z

Modell:	DEAPT50Z
Versiegelungsgeschwindigkeit	360-500 Pcs/H
Verpackungsgröße	L400-600 × B300-500 × H150-300 mm
Stromversorgung	80 V, 50 Hz, 6 kW
Luftdruck	600 NL/min, 0,5–0,6 MPa
Höhe des Ausgabetisches	600 mm
Maschinenabmessungen	L 2200 × B 1800 × H 1950 mm

Buy bag inserters – enquire now

Are you interested in our bag inserter machine or would you like some no-obligation advice from our packaging experts? Contact us on +49 - 2235-79479-0 or by email at info_at_alphapack.de.We look forward to optimizing your packaging line.

Bag inserter machine for efficient packaging processes

Automated insertion of bags into cartons, trays, and KLT containers
