Filling and Capping Machines for Containers and Jars

Präzisionstechnik für industrielle Verpackungsprozesse

Using a non-contact procedure, our container capping machines heat the inside seal and finally hermetically cap plastic and glass containers. This capping process takes place after filling and sealing the containers (with lids). The production capacity counts up to 300 units per minute. Our container capping machines which can be used also on fast conveyor belts are the ideal solution for high speed packaging processes and the first choice for mass production.

👁

Advantages of our container capping machines

High capacity: Ideal for mass production
Continuous performance: Reliable sealing capacity for uninterrupted packaging processes
Flexible integration: Can be integrated into existing systems or used separately
Precise sealing: Hermetic closure for optimum product freshness and safety
Energy-efficient technology: Optimised heating processes reduce energy consumption
Versatile application options: Suitable for a wide variety of container shapes and materials

👁

Areas of application

Our container filling and capping machines are successfully used in numerous industries:

Food

Capping trays with pastries
Ketchup in trays
Spices in trays
Salt in cans
Ready meals
Sauces and dressings
Dairy

Pharmaceutical and cosmetics

Food supplements
Tablets and capsules
Creams and ointments
Medical preparations

Container capping machine for powder filling

Filling and capping cans with food supplements

Container capping machines for food packaging

Container capping machine for spice packaging

Model options:

DETAPI-2001A

Model: DETAPI-2001A
Voltage: 220 V / 1 pH, 50 Hz
Maximum power:
2500 W
Sealing diameter: A:15 - 45 mm, B:30 - 60 mm, C: 50 - 120 mm
Maximum capacity:
200
Cooling method: air cooling
DETAPI-2001B

Model: DETAPI-2001B
Voltage: 220 V / 1 pH, 50 Hz
Maximum power:
2500 W
Sealing diameter: A:15 - 45 mm, B:30 - 60 mm, C: 50 - 120 mm
Maximum capacity:
200
Cooling method: air cooling
DETAPI-3000A

Model: DETAPI-3000A
Voltage: 220 V / 1 pH, 50 Hz
Maximum power:
3000 W
Sealing diameter: A:30 - 60 mm, B: 50 - 121 mm
Maximum capacity:
300
Cooling method: water cooling
DETAPI-3000B

Model: DETAPI-3000B
Voltage: 220 V / 1 pH, 50 Hz
Maximum power:
3000 W
Sealing diameter: A:30 - 60 mm, B: 50 - 121 mm
Maximum capacity:
300
Cooling method: water cooling

Model:	DETAPI-2001A
Voltage:	220 V / 1 pH, 50 Hz
Maximum power:	2500 W
Sealing diameter:	A:15 - 45 mm, B:30 - 60 mm, C: 50 - 120 mm
Maximum capacity:	200
Cooling method:	air cooling

Model:	DETAPI-2001B
Voltage:	220 V / 1 pH, 50 Hz
Maximum power:	2500 W
Sealing diameter:	A:15 - 45 mm, B:30 - 60 mm, C: 50 - 120 mm
Maximum capacity:	200
Cooling method:	air cooling

Model:	DETAPI-3000A
Voltage:	220 V / 1 pH, 50 Hz
Maximum power:	3000 W
Sealing diameter:	A:30 - 60 mm, B: 50 - 121 mm
Maximum capacity:	300
Cooling method:	water cooling

Model:	DETAPI-3000B
Voltage:	220 V / 1 pH, 50 Hz
Maximum power:	3000 W
Sealing diameter:	A:30 - 60 mm, B: 50 - 121 mm
Maximum capacity:	300
Cooling method:	water cooling

Buy filling and capping machines for containers – Enquire now

Are you interested in our filling and capping machines for containers, or would you like some no-obligation advice from our packaging experts? Get in touch with us on +49 - 2235-79479-0 or by email at info_at_alphapack.de. We look forward to optimising your packaging line.
