Angle Welding Machine

Precise welding technology for cost-optimised product packaging

With the angle welding machine (L-angle) from the WSG series, your products can be packaged quickly and cost-effectively in a single step using film separation welding. The product is placed in the angle welding machine, which is triggered manually or pneumatically. The welding frame opens automatically and the product can optionally be fed into a separate shrink tunnel. The high-quality components and our sophisticated impulse wire technology guarantee high-strength weld seams and low-maintenance operation. The easy handling of the angle welders guarantees flexible and time-saving packaging for large throughput quantities. Customised weld frame sizes or continuously heated weld knives are available on enquiry.

👁

Technical details and functional features

Robust design with steel frame construction for long-term industrial use
Individually combinable with different shrink tunnels for a complete packaging solution
Teflon-coated impulse heating band to reduce film sticking
Electronic adjustment of sealing time, discharge belt speed and sealing cycle
Electromechanical sealing frame closure with holding magnet for secure closure
Mobile design on castors with locking brakes for flexible handling
Movable film carriage including film perforation unit for easy material guidance
Optional pneumatic operation with foot switch, timer or two-hand control
Optional continuously heated system for special applications and higher throughput

👁

Direct applications at a glance

Printed products: book packaging, catalogues, brochures
Office supplies: Cardboard boxes, mailings, document folders
Media: CDs, DVDs, data storage devices
Food: Individual packaging, containers, sample packs
Small parts: Assortments, bundles, sales units
Electronics: Components, accessories, cable sets
Industrial products: Tools, spare parts, components

Our angle welding machines in use

Shrinking tools with an angle welding machine

Shrinking products in PE film

Model options

WSG-4055

Model:	WSG-4055
Usable films (center folded):	POF / PP / PE / PVC
Maximum film thickness:	60 my
Sealing frame size:	400 x 550 mm
Maximum product dimension:	380 x 520 x 200 mm*
Maximum reel size (L x Ø):	600 x Ø 250 mm*
Machine size:	1600 x 775 x 1100 mm
Connected load (maximum):	1,2 kW
Supply voltage:	230 V
Machine weight (approx.):	150 kg
Shrinking process:	up to 15 pieces / minute **
Pneumatic sealing frame:	optional / 5,5 bar

WSG-5070

Model:	WSG-5070
Usable films (center folded):	POF / PP / PE / PVC
Maximum film thickness:	60 my
Sealing frame size:	500 x 700 mm
Maximum product dimension:	480 x 680 x 200 mm*
Maximum reel size (L x Ø):	600 x Ø 250 mm*
Machine size:	1900 x 875 x 1100 mm
Connected load (maximum):	1,8 kW
Supply voltage:	230 V
Machine weight (approx.):	230 kg
Shrinking process:	up to 15 pieces / minute**
Pneumatic sealing frame:	optional / 5,5 bar

WSG-75100

Model:	WSG-75100
Usable films (center folded):	POF / PP / PE / PVC
Maximum film thickness:	60 my
Sealing frame size:	750 x 1000 mm
Maximum product dimension:	720 x 980 x 200 mm*
Maximum reel size (L x Ø):	800 x Ø 250 mm*
Machine size:	2910 x 1300 x 1100 mm
Connected load (maximum):	2,8 kW
Supply voltage:	230 V
Machine weight (approx.):	350 kg
Shrinking process:	up to 15 pieces / minute**
Pneumatic sealing frame:	optional / 5,5 bar

WSG-100120

Model:	WSG-100120
Usable films (center folded):	POF / PP / PE / PVC
Maximum film thickness:	60 my
Sealing frame size:	1000 x 1200 mm
Maximum product dimension:	980 x 1180 x 200 mm*
Maximum reel size (L x Ø):	950 x Ø 250 mm*
Machine size:	2500 x 1125 x 1000 mm
Connected load (maximum):	3,4 kW
Supply voltage:	400 V / 3-Phasen
Machine weight (approx.):	480 kg
Shrinking process:	up to 15 pieces / minute**
Pneumatic sealing frame:	optional / 6,0 bar

Buy angle welding machine - Enquire now

Are you interested in our angle welding machine or would you like some no-obligation advice from our packaging experts? Contact us on +49 - 2235-79479-0 or by email at info_at_alphapack.de. We look forward to optimising your packaging line.

The right foil for angle welding machines

Verpackung von Süßigkeiten mit OPP-Siegelfolie

Polyolefin Fine Shrink Film

Polyolefin fine shrink films are among the most popular materials in film packaging. They are extremely thin, highly transparent, and recyclable. Unlike PE films, POF shrink films shrink without wrinkles and fit around your product like a second skin.

Getränke im Tray verpackt mit Polyolefin Feinschrumpffolie

PE Shrink Film

Our PE shrink film provides your products with optimum protection against external influences such as dirt and even acids and alkalis. It is food-safe, highly transparent and has high tear resistance.

An L-angle sealer (also known as an L-angle welding machine) is a semi-automatic or manual packaging machine used to seal products in film. The sealing wires are arranged in an L-shape and seal the film on two sides simultaneously.

Ideal for:

Books, magazines, calendars
Food items such as baked goods or pizza
Electronic products, DVDs, household goods
Sets, promotional items and much more

The angle welder creates visually appealing packaging that protects against dust and moisture.

An angle welder works with fixed sealing angles and is particularly suitable for individual packaging. A side sealer is better suited for long series or changing product formats and allows endless sealing seams in the direction of travel.

Typical examples are:

Polyolefin fine shrink film (POF)
PVC shrink film (for promotional goods)
Thin PE films (limited)

POF is particularly well suited for its brilliant appearance and recyclability.

Easy to operate with minimal training required
Compact design for small production areas
Cost-effective for medium packaging volumes
Can be optionally combined with a shrink tunnel for a perfect film fit
