Side Labelling Machine

Precise marking technology for round and irregular products

With our high-performance side labelling machines, you can label your products fully automatically. Our label systems can apply labels to flat or oval containers as well as round products such as bottles, tablet containers, sausage products or wax crayons. Our machines can either apply labels all the way round or label the front and back simultaneously.

👁

Technical details and functional features

Robust construction: Stainless steel housing for long-lasting industrial use
Intuitive operation: Programmable control via touchscreen
Highest precision: Highly accurate labelling with ±1 mm tolerance
Automatic synchronisation: Servo-controlled labelling head; labelling speed is automatically synchronised with the throughput speed of the products
Optimal product guidance: With bottle positioner and separating wheel (depending on model)
Perfect results: With automatic push & press sponge installation for wrinkle- and bubble-free labelling (depending on model)

👁

Advantages of side labelling technology

Versatility: Processing of round, oval or irregularly shaped products
Flexibility: Choice of all-round or front/back labelling
Efficiency: High processing speed with maximum precision
Reliability: Consistent labelling quality even during long production runs
Adaptability: Quick changeover for different product types and label formats
User-friendliness: Simple programming and operation via intuitive touchscreen
Integratability: Easy integration into existing production lines

Model options:

DEALB-210A

Model: DEALB-210A
Label width: 10 - 110 mm
Label length: 10 - 250 mm*
Product diameter/ width: 15 - 160 mm
Labeling speed: 12 - 35 m / min**
Machine size (L x W X H): 1450 x 700 x 1550mm

DEALB-215

Model:	DEALB-215
Label height/width:	A: 10 - 110 mm; C: 10 - 170 mm*
Label length:	15 - 80 mm*
Product diameter/ width:	10 - 25 mm
Labeling speed:	12 - 35 m / min**
Reel: inner / outer diameter:	between 76 mm / 360 mm

DEALB-515

Model:	DEALB-515
Label height/ width:	A: 10 - 110 mm; C: 10 - 170mm*
Label length:	10 - 300 mm*
Product diameter/ width:	25 - 100 mm
Labeling speed:	12 - 35 m / min**
Reel: inner / outer diameter:	between 76 mm / 360 mm
Machine dimensions (L x W x H):	2100 mm x 1110 mm x 1550 mm

DEALB-620

Model:	DEALB-620
Label height / width:	A: 10 - 110 mm; C: 10 - 170 mm; D: 10 - 220 mm*
Label length:	10 - 250 mm*
Product diameter / width:	30 - 100 mm (larger on request)
Labeling speed:	12 - 25 m / min**
Reel: inner / outer diameter:	between 76 mm / 360 mm
Machine dimensions (L x W x H):	2750 mm x 1400 mm x 1665 mm

DEALB-620R

Model:	DEALB-620R
Label height / width:	A: 10 - 110 mm; C: 10 - 170 mm; D: 10 - 220 mm*
Label length:	10 - 250 mm*
Product diameter / width:	30 - 100 mm (larger on request)
Labeling speed:	12 - 25 m / min**
Reel: inner / outer diameter:	between 76 mm / 360 mm
Machine dimensions (L x W x H):	2750 mm x 1400 mm x 1665 mm

DEALB-625

Model:	DEALB-625
Label height / width:	A: 10 - 110 mm; C: 10 - 170 mm; D: 10 - 220 mm*
Label length:	10 - 250 mm*
Product diameter / width:	30 - 100 mm (larger on request)
Labeling speed:	12 - 25 m / min**
Reel: inner / outer diameter:	between 76 mm / 360 mm
Machine dimensions (L x W x H):	2750 mm x 1400 mm x 1665 mm

Buy side labelling machine - Enquire now

Are you interested in our side labelling machine or would you like to receive non-binding advice from our packaging experts? Contact us at +49 - 2235-79479-0 or by email at info_at_alphapack.de. We look forward to optimizing your packaging line.
