Linear Weigher

Precise dosing and filling technology for sensitive products

Gentle weighing solution with minimal drop height

The linear weighers are universally applicable – both in the food and non-food sectors. Thanks to its low drop height, the linear weigher even reliably fills sensitive and fragile products. With our linear weigher, you can fill preformed bags and pouches quickly and easily.

All machine parts are made of stainless steel, making our linear weigher the ideal weighing and filling solution in any production environment.

👁 👁

Functional principle and advantages

The linear weigher works according to a simple but effective principle: the product is transported via linear conveyor belts or vibrating channels and precisely weighed. In contrast to rotating multihead weighers, the product is handled particularly gently as the drop height is minimised. This technology offers decisive advantages:

👁
  • Gentle processing: Ideal for sensitive and fragile goods
  • High precision: Weight accuracy even with difficult product characteristics
  • Flexible use: Versatile for a wide range of products
  • Easy cleaning: Hygienic design with stainless components
  • Quick changeover: Uncomplicated changeover between different products
  • Maintenance-friendly: Robust construction with low maintenance requirements
  • Space-saving: Compact design for optimum use of space

Our linear weighers in use

Precise filling of spices with linear weigher and sealing machine

Efficient filling of pulled pork with linear weigher and SBM-420

Model options:

  • MHW-AX1-00
    Model:MHW-AX1-00
    Heads:1
    Levels:1
    Hopper Volume:3 L
    Filling Weight:20-2000 g

  • MHW-AX2-2-1
    Model:MHW-AX2-2-1
    Heads:2
    Levels:1
    Hopper Volume:15 L
    Filling Weight:1000 - 12000 g

  • MHW-AX2-2-2
    Model:MHW-AX2-2-2
    Heads:2
    Levels:1
    Hopper Volume:4,5 L
    Filling Weight:50-3000 g

  • MHW-AX4-2-1
    Model:MHW-AX4-2-1
    Heads:4
    Levels:1
    Hopper Volume:0,5 L
    Filling Weight:5-300 g

  • MHW-AX4-2-2
    Model:MHW-AX4-2-2
    Heads:4
    Levels:1
    Hopper Volume:3 L
    Filling Weight:50-2000 g

  • MHW-04L
    Model:MHW-04L
    Heads:4
    Levels:1
    Hopper Volume:3 L
    Filling Weight:20-2000 g
    Accuracy:0,2-2 g
    Max. Speed:50 ppm**

  • MHW-04S
    Model:MHW-04S
    Heads:4
    Levels:1
    Hopper Volume:0,5 L
    Filling Weight:5-200 g
    Accuracy:0,2-1 g
    Max. Speed:60 ppm**

  • MHW-02L
    Model:MHW-02L
    Heads:2
    Levels:1
    Hopper Volume:15 L
    Filling Weight:500-10000 g
    Accuracy:1-10 g
    Max. Speed:20 ppm**

  • MHW-02S
    Model:MHW-02S
    Heads:2
    Levels:1
    Hopper Volume:4,5 L
    Filling Weight:100-3000 g
    Accuracy:0,5-3,0 g
    Max. Speed:30 ppm**

  • MHW-01S
    Model:MHW-01S
    Heads:1
    Levels:1
    Hopper Volume:4,5 L
    Filling Weight:100-1500 g
    Accuracy:1,0-3,0 g
    Max. Speed:15 ppm**

Buy linear weigher - Enquire now

Are you interested in our linear weigher or would you like some no-obligation advice from our packaging experts? Contact us on +49 - 2235-79479-0 or by email at info_at_alphapack.de. We look forward to optimising your packaging line.
